Flexible Bottom High Speed Door - 990

Model 990

Interior and exterior high speed fabric doors that provide the utmost in efficiency, reliability and return on investment.

CALL (608) 271-4288
GET A QUOTE

Overview

Our flexible bottom high speed interior fabric door, RapidFlex® 990, is ideal for high-traffic manufacturing, pharmaceutical, warehouse and distribution facilities. Built for safety this door features a flexible bottom with wireless monitored reversing edge, built-in drop stop device and in-plane infrared sensors.

A simple black and white line drawing of a bicycle, shown from the side. The illustration clearly displays the wheels, frame, handlebars, seat, pedals, and chain.

Wide array of
stained and painted finishes

A person sits cross-legged on the floor meditating, with hands resting on their knees. A large clock is behind them, symbolizing mindfulness and taking time to meditate. The background is blank.

Wood-grain
texture

A stick figure sitting at a desk raises its arms in frustration while looking at a computer monitor, with a slanted desk lamp overhead.

Customize with windows and hardware

A person in a wheelchair is depicted ascending a flight of stairs using a stair lift, illustrating accessibility solutions for individuals with mobility impairments.

Superior thermal performance

A black cat sits on a windowsill, looking outside. Sunlight streams through the window, casting a warm glow on the cat’s fur and the surrounding area. Lush green trees can be seen outside the window.

Superior
durability

A silhouette of a person with their head resting on their hand, appearing thoughtful or contemplative.

Wind load options
upon request

Colors

Colors

Close-up of a red surface with a textured pattern of small, evenly spaced, raised circular bumps. The light reflects off the bumps, creating a sense of depth and dimension.

Red

Close-up of a textured blue surface with a repeating pattern of small, raised hexagonal bumps, creating a geometric and slightly reflective appearance.

Blue (Textured)

A close-up view of a surface with a regular pattern of small, raised bumps arranged in rows, creating a textured and slightly reflective appearance. The surface is light gray or off-white.

Gray

White background with a subtle, repeating geometric pattern of faint diamond shapes, giving it a textured and modern appearance. The overall look is clean, minimal, and light.

Dark Bronze

Bottom Bar & Guide

A solid bright yellow background fills the entire image. There are no patterns, objects, or visible details other than the uniform yellow color.

Red

White background with a subtle, repeating geometric pattern of faint diamond shapes, giving it a textured and modern appearance. The overall look is clean, minimal, and light.

Dark Bronze

RAL Powder Coat

Actual door color may vary from the digital representation shown here. Color samples are available by request through your Overhead Door™ Distributor. The standard color for guides, brackets, and bottom bar is yellow. 197 optional RAL powder coat color options are available.

Vertical stripes in a rainbow spectrum, transitioning smoothly from black and brown on the left through shades of blue, green, yellow, orange, and red on the right. The stripes are bright and evenly spaced.

Enhancements

Actuation options

Push button, key switch, pull switch, motion detector, radio control, loop detector, treadle switch ; Wireless options: pull switches, 1 or 3 button push button, palm button

Signal device options

Red/green LED warning light, horn/strobe combination, rotating warning light

Programmable LED lighting system

Tall light bar with red, yellow, green lighting

20″ high vision panels

Spaced evenly across width of door

Brochures

High Speed Doors Brochure - Model 990

Download PDF

High Speed Doors Brochure

Download PDF

High Speed Doors Light Curtain Options

Download PDF

Documents

Explore the full specifications of our products. Our technical data sheets provide comprehensive information on dimensions, assembly methods, and construction requirements. Make well-informed decisions by planning your investment down to the last detail.

BIM

RapidFlex® Model 990 High Speed Interior Fabric Door BIM Model

Download BIM

Shop Drawing

RapidFlex High Speed Interior Fabric Door Model 990 CAD (DWG)

Download DWG

RapidFlex High Speed Interior Fabric Door Model 990 CAD (PDF)

Download PDF

Specifications

High Speed Doors - Model 990 Specs

Download PDF
Download DOC

Product Literature

High Speed Doors Light Curtain Options

Download PDF

High Speed Doors Brochure

Download PDF

High Speed Doors Brochure - Model 990

Download PDF

Warranty

5-year limited on drive motor and gearbox; 1-year limited on all other available components

Construction

Product Specifications

Standard Max Width12′
Standard Max Width12′
MaterialPVC/Polyester
SpeedUp to 70″ per second
Curtain LockPatent-pending curtain-lock design allows for quick and easy repair in the field
Break-Away Self-ResetDesigned to break away from the side guides to minimize damage and simply reset and self-repair after the event
Wind Load*Up to 3.0 psf
Door Panel2 thin layers of PVC coated polyester; 1 layer of polyester weave
OperationDirect drive motor and gearbox system with a door stop device
Control Panel
  • Variable frequency drive
  • NEMA 4X cULus listed
  • Onboard self diagnostic and service reminder
  • Built-in padlockable field disconnect
Obstruction DetectionInfrared sensors mounted in-plane to the door curtain at 6″ and 50″-54″ from floor
Reversing Safety EdgeWireless reversing edge; Flexible bottom bar with detachable bottom seal
Electrical Availability**120V AC 1PH; 208V AC 1PH†; 220V AC 1PH; 208V AC 3PH†; 230V AC 3PH; 460V AC 3PH; 575V AC 3PH†

* Pressure/wind resistance value is the ultimate pressure tested at door width of 12′.
**Single phase available up to 10’ doors.
†Requires stand-alone mounted transformer
